Technical data Red Dragon® 5 ECO pump 130 Watt 11,0 m³:
130 Watt/h 6,9 mtr. pressure height
Speed adjustable Brushless DC pump
Watt-, Power consumption and Revolution per minute (rpm) – Display
Adjustable in 2-watt-steps from 2W up to 130W
intake side 40 mm (1.25″) – pressure side 32 mm (1″)
Operating voltage: 100-240 Volt 50-60 Hz (24V Technology)
Protection class pump: IP 68 control unit: IP 66
Weight pump without controller: 3,5 kg
Height of intake side: center 75 mm
Dimension pump: 130 mm wide / 230 mm length / ~ 190 mm height
Dimension control unit: 50 mm wide / 100 mm length / ~ 190 mm height
Operating_and_maintenance_manual.pdf
- Saltwater resistant M5 grade 2 titanium screws
- Saltwater resistant parabolic rubber feet for acoustic decoupling
- Extreme low noise brushless DC-delivery pump with external power electronics
- High efficient technology, Sine Wave for very quiet running
- Inlet and Outlet complete with DIN connection, compact dimensions
- Easy usage and maintenance, low risk of calcification
- Heavy and massive craftsmanship against vibrations and oscillation
- CE conformity, developed and built
- quality power supply from “Mean Well“
- high quality touchscreen display with a lot extra functions
(protection against dry-running, over heating, over voltage, blocking etc.) - 10V connection/controlling with 3.5mm TS-connector (phone jack)
- 3m cable between pump and controller
- 1,5m cable plug connection EU/US (Rubber connector)
